Rotary UV Engraving Printer


| Output Device | UV laser digital Engraver | Laser phototypesetting machine | Wax-jet machine | Inkjet machine |
| Screen effect | Best seamless splicing, laser direct exposure, not affected by externalenvironment |
Worse after printing to solve |
Better nozzle used for a period of time will be tailored, twisted, will cause the net making fine degree is reduced |
Worse ink permeates outward diffusion |
| Technology | Easy | Complex (package the film) | Easy | Easy |
| Cost | Low without the need for film, wax block, ink and other supplies |
High need for photosensitice film and other suppline |
High 1. need to use wax block 2. the nozzle is expensive, short service life, working distance, prone to accidental damage |
High 1. need to use ink 2. The service life of the nozzle is short, working distance, prone to accidental damage |
| Rotary UV Engraving TECHNICAL SPECIFICATION | ||
|---|---|---|
| Mode: | RUV 2200/RUV 3500 | |
| Imaging system: | 16-24 channel discrete 405nm laser diode | |
| Resolution: | 720-2540 dpi | |
| Engraving speed: | 5-8min./m | |
| Repeatability: | 0.02mm continuous exposure for 2 times at 25 dc and 60% relative humidity. | |
| Interface: | USB 2.0 | |
| Emulsion: | Dedicated Photo Emulsion | |
| Image size: | 640-1018mm | |
| Screen length: | 300-2200/3500mm | |
| File type: | bmp/tif | |
| Power: | 220v-50hz-2kv | |
| Environment: | Recommended 21-25 dc. Feasible 18-26 dc, relative humidity 40-70%, dust-free, constant temperature. | |
| Size/weight: | 3700*1000*1500mm/1200kg(packing included) & 4700*1000*1500mm/1500kg(packing included) | |
| UV lamp: | NICHIA, japan origin | |
| Service life of UV lamp: | 20000 hours | |
| Motor: | SIEMENS/PANASONIC | |
| Panel component: | SIEMENS | |
| Warranty: | 1 year warranty for whole body. | |
| Operation language: | ENGLISH | |
| Software: | Full set of software included in the package | |
